OptiFPP: Cold Filter Plugging Point

State-of-the-Art Solution

Designed to increase the laboratory productivity through automation, the ISL OptiFPP measures the Cold Filter Plugging Point of diesel fuels completely unattended, therefore reducing the operator time but also improving greatly the analysis performance.

Product Overview Key Features Specs Consumables Documentation Related Resources Request a Demo or a Quote

Product Overview

The next generation Cold Filter Plugging Point analyzer combines a patented built-in cooling system and highly precise detection mechanism into an ultra-compact, easy to use instrument. The ISL OptiFPP analyzer provides automated CFPP test in strict accordance to ASTM D6371, EN 116 and EN 16329 conditions. OptiFPP precisely controls jacket cooling and electronically controlled vacuum adjusts as the test specimen is drawn though a mesh filter, per method conditions. Once crystal formation inhibits sample flow within a set time, a CFPP value is detected, displayed and stored to memory. Detailed reports are available, showing any abnormal points, as well as sample temperature behavior during the test.

The Cloud Point Kit is available with a stainless steel and a glass temperature sensor. A complete measuring head with a probe, filter unit and pipet is also available for purchase.

Key Features

Compact Design with Built-in Cooling System

Fully self-contained cooling system

Real-time display of test progress and results

Stand-alone and/or PC controlled operation

Specs

Standard Test Methods

CFPP: EN 116, EN 16329, IP 309, ASTM D 6371, JIS K 2288
CP: In accordance with ASTM D5771, IP 444, EN 23015, EN 590
In correlation to ASTM D2500, ISO 3015, IP 219, JIS K2269
Customized: up to 5 methods (stand-alone mode); unlimited (PC connection mode)

Analytical Principle

Aspiration of cooled diesel and domestic heating fuels through a filter into a volumetric pipette within 60 seconds

Cooling System

Internal Stirling Cooling
• Stepped or linear cooling profiles according to method or user defined (sample or jacket adjustable from
1°C/h to 120°C/h)
• Customizable up to 20 steps

Temperature Range

Sample: – 95°C to +51°C (-139°F to 123°F)
Jacket: -105°C to + 55°C (-157°F to +131°F) Automatic control of programmable cooling steps

Sample Temperature

Accuracy: 0.1°C Metal/Glass Pt100 probe IEC DIN 751 1/3 class B
Automatic calibration of measurement circuit and 20 points probe correction table

Cooling Temperature

Accuracy: 0.5°C Metal Pt100 probe
Automatic calibration procedure

Sample Volume

Around 45 ml

Calibration

Automatic temperature calibration routine. 2 to 10 points temperature probe correction table
Programmable calibration frequency

Power Requirements

90–240 VAC, (+/- 10 %) V – automatic adaptation, INDOOR USE ONLY

Environmental Conditions

Operating temp: 10 to 35°C (50 to 95°F) Storage temp: -20 to 50°C (-4 to 122°F)

Frequency

50/60 Hz

Wattage

300W

Data Management

Documentation: Real-time display on screen of test progress & graphics, Quality Control Database, Self diagnosis tool
Internal Memory: 200 test runs with graphic result and cooling curve.
Quality Control Database: Control of up to 30 Quality Control products with automatic acceptance criteria; deviations and statistical quality reports.
Each quality control chart can store up to 40 points. Devices calibration history and printable ticket
PC Networking: IRIS software connection for multi-instrument networking
Printing: Personal/Network printer; 40/80 columns/PCL5
Display: 7” color touch-screen
Data Input/Output: 2 USB ports, 1 Ethernet port, 1 RS232C serial link for direct connection to LIMS or external PC
Password Security: Multi-level password protection. Customer configurable

Physical Specs

Dimensions L x W x H: 700 x 454 x 350 mm (27.6 x 10 x 17.8 in) With second holder: 700 x 500 x 350 mm (27.6 x 19.7x 13.8 in)
Weight: 30 kg (67 lbs) and 30.7 kg (67.7 lbs) with measurement head

Consumables

100662 Set of 3 * O-Rings for CFPP filter, solvents & FAMEs compatible 01000-309-51 CRM CFPP Diesel Fuel 255 Ml: Certified Reference Material (CRM)CFPP reference oil -19,7Celcius, approx. 255ml 01000-309-52 CRM CFPP appr. -25°C, 255ml 102700-5 Set of 5 Thermal Paper Roll 80mm 1108-002-000 Set of 10 V-Ring FFKM Diameter 6 for OptiFPP Head 1108-002-001 Set of 4 V-Ring FFKM Diameter 6 for OptiFPP Head 1109-000-000 Set of 10 Fuses 5x20 5A 2205-010-001 CFPP PIPETTE 20ml M004234 Tube, Test, FFP 5G, OptiFPP Q0330303 Set, gauze, filter, 10 pc Q2210401 Fpp Insulating Ring and Spacer V033102 COMPLETE FILTER UNIT - Compatible Solvents & FAMEs V033102-SS COMPLETE FILTER UNIT - Compatible Solvents & FAMEs—SS

Documentation

Title	Description	PDF
Brochure	OptiFPP Brochure	Download
Safety Data Sheet	CRM Diesels SDS	Download
